QYT KT-8900 Mini Mobile Radio Dual band 136-174MHz 400-480MHz 25W Transceiver KT8900 Car Walkie Talkie

Main features:

QYT KT-8900 Upgraded Version (with 3.5mm PTT Earphone Connector)

Dual Band, VHF:136-174MHz UHF:400-480MHz

Comes with 2 Tone,5 Tone,DTMF functions

Dual Display,Dual Standby

Mini Compact Size,Dimensions:98(W) x 35(H) x 118(D)mm

RF Output Power: 25W/20W(VHF/UHF)

Specifications:

Item number QYT KT-8900 MINI Mobile Radio

General

Frequency Range VHF:136-174MHz UHF:400-480MHz

Number of Channel 200

Channel Spacing 25KHz 20K 12.5

Phase lock step 5KHz, 6.25 KHz, 10 KHz ,12.5 KHz, 15 KHz, 25 KHz

Working Voltage 13.8V DC±15%

Squelch way CTCSS/DCS/5Tone/2Tone/DTMF

Frequency Stability ±2.5ppm

Operating Temperature -20~+60

Dimension(W x H x D) 98(W) x 35(H) x 118(D)mm

Weight 408g

Receiver

Broadband Narrow band

Sensitivity 0.25V 0.35V

Channel choice 70dB 60dB

Intermodulation 65dB 60dB

Spurious Rejection 70dB 70dB

Audio response +1~ -3dB(0.3~3KHz) +1~ -3dB(0.3~2.55KHz)

Signal to noise ratio 45dB 40dB

Audio distortion 5%

Audio output power 2W@10%

Transmitter

Broadband Narrow band

Output power 25W/20W(VHF/UHF)

Modulation Mode 16KF3E 11KF3E

Channel Power 70dB 60B

Signal to noise ratio 40dB 36dB

Parasitic harmonic 60dB 60dB

Audio response +1~ -3dB(0.3~3KHz) +1~ -3dB(0.3~2.55KHz)

Audio distortion 5%

ONE STANDARD PACKAGE INCLUDES:

1 X QYT KT-8900 Radio

1 X Microphone with Keypad

1 X DC Power Cable (with Cigarette Lighter)

1 X Mounting Bracket

1 X Mounting Screws Kit

1 X English User's manual
