Gigabit Ethernet Switch Fiber Optical switch Industrial Grade 4 1.25G sfp Fiber Port 2 RJ45 10/100/1000M PCB board

{{ product.price_format }}
{{ product.origin_price_format }}
Quantity:
seller: 123
Star rating:
Total sales: 0

{{ variable.name }}

{{ value.name }}
This product is unavailable in your region Confirm
Product Details Evaluations

Transmission distance : 20km

Model Number : JYD-SFP0402

Certification : CE

Product Name : Fiber Switch

Switch Type : Gigabit Swtich

Fbier Port : 4 SFP fiber port 1.25G

Ethernet Port : 2 RJ45 port 10/100/1000M

Wavelength : 1310/1550nm

communication Mode : Full-Duplex&Half-Duplex

Power Supply : DC12V 2A AC100V-240V(50-60HZ)







Gigabit Ethernet Switch 4G2E Series Fiber Switch

The Gigabit 4G2E is an Ethernet Fiber Switch which is specially designed for network monitoring. It
has 2*10/100/1000Mbps Ethernet ports and 4*1.25Gbps sfp fiber ports. It adopts Marvell chips to ensure
low power consumption and high stability. It extends the transmission distance of a network from
100m to 120km via copper cables. It can extend the transmission distance; there are also many other
advantages such as isolation protection, good data security, working stability and easy maintenance.

Main Features:

1.Support the switch between 10/100/1000Base-TX and 1000Base-SX/LX
2.4*1.25Gbps sfp fiber ports and 2*10/100/1000M Ethernet ports with auto-negotiation function
3.Support 1000M speed rate, MDI/MDIX and half/full-duplex with auto-negotiation function
4.Each port has the complete LED Indicator light
5.Support single mode single fiber,single mode dual fiber ,multi-mode dual fiber and SFP slot
6.Support IEEE802.1d Spanning Tree
7.Support high performance QoS function on each port
8.Support 5V voltage input
9.Support IEEE 802.3x flow control and back pressure control
10.Require no configuration and will instantly operate as soon as you power it up
11.Low power consumption chip with heat sink built in to ensure longtime efficient operation



Specifications:



Standards

IEEE802.3 10Base-T

IEEE802.3u 100Base-TX/FX

IEEE802.3z 1000Base-SX/LX

IEEE802.3x Flow control

IEEE802.1p QoS

IEEE802.1d Spanning Tree


Ethernet Port

Connector: RJ45

Data Rate:10/100M or 10/100/1000M

Distance: 100m

UTP Type: UTP-5E or higher level

Fiber Port

Connector: SC/FC/ST/SFP slot

Data Rate: 155M or 1.25Gbps

Optical Wavelength: 850nm/1310nm/1490nm/1550nm

Distance: 550m～120km

Performance

Processing Type: Store and Forward

MAC Table Size:4K/6K/8K

Buffer Space: 500kbs/1Mbit/2Mbit

Jumbo Packet: 1518 bytes

Back bandwidth: 3.8G/5.6G/7.2G

Time Delay: ＜150μs

Power

Power type: external power supply

Input Voltage: AC100V～240V 50/60Hz

Connector: DC Socket

Working Voltage: 5V

Power Consumption: 2.2W～3.5W

Transmissin Distance

Twisted Pair: 100m (CAT5e, CAT6 cables)

Muti-mode: 2km

Single-mode: 3/20/40/60/80/100km

MTBF

100, 000 hours

Warranty

1 year

Environment

Storage Temperature: -40～70℃

Operating Temperature: -10～55℃

Relative Humidity: 5-90% ( no condensation)

Mechanical Structures

Dimension: 215×107×26mm

Weight: 0.15

PCB  main board

OEM&ODM

Supportive
